Lithium battery Microwave induction 40w - 120w High power solar induction street lamp
Features
1.Solar powered led street lights are designed by MINSENS for outdoor road lighting.
2.Maximum power can reach 120W, which can support municipal road lighting needs.
3.Folding solar panels are used to increase the configuration requirements.
4.Various intelligent control schemes can be set up, energy saving and environmental protection.
5.Protection against electric shock: Class Ⅲ
6.Use anodic oxidation process on lamp surface with strong corrosion resistance and weather resistance, suitable for various complex environments.
7.The lens adopts high-quality imported optical-grade materials, with accurate light distribution, high efficiency and strong weather resistance.
8.Various light distribution angles are available.（Support OEM/ODM Service）
Specification
|
Led Source |
FX-40W |
FX-50W |
FX-60W |
FX-80W |
FX-100W |
FX-120W |
|
Mono Solar Panel |
18V 65W |
18V 70W |
18V 80W |
18V 100W |
18V 130W |
18V 140W |
|
LifePO4 Battery |
12.8V 27AH |
12.8V 36AH |
12.8V 42AH |
12.8V 57AH |
12.8V 63AH |
12.8V 72AH |
|
LED（Bridgelux） |
3030/96PCS |
3030/144PCS |
3030/144PCS |
3030/192PCS |
3030/240PCS |
3030/288PCS |
|
Color Temperature |
2700K-6500K，RA>70 |
|||||
|
Brightness |
220LM/W |
|||||
|
Working Time |
12-15hours, 10-12 cloudy/ rainy days |
|||||
|
Charging Time |
6-8hours |
|||||
|
Mounting Caliber |
70-76mm（suggestion） |
|||||
|
Working Temperature |
-25℃－+65℃ |
|||||
|
Body Sensor |
160°，>9m , Activated by customer’s need |
|||||
|
Battery Power Indicators |
100%-75%-50%-25% |
|||||
|
Fault indicator |
RED/BLUE/GREEN |
|||||
|
IP Rating/IK Class |
IP65/IK10 |
|||||
|
Mounting Height |
6-7m |
6-8m |
6-8m |
8-9m |
9-11m |
10-12m |
|
Space between 2 lamps |
20-25m |
20-25m |
20-25m |
25-30m |
30-35m |
35-40m |
|
Warranty |
3 years / 5 years |
|||||
Details
Applications
Solar Lighting Applications: Area Lighting; Airport Lighting ; Hospital parking ; Parking Lot lighting ; Highway Roadway Lighting ; Street Lighting ; Security lighting ; Highway and ramp Lighting ; Brige Lighting , Under pass Lighting ; Brige Lighting , Under pass Lighting ; Military security Lighting and so on.
